SMT6H-Dark Sky Friendly LED Bollards from RAB Lighting Avoid Uplight and Glare in Outdoor Urban Settings
March 16, 2023
The Summit Series is a dark sky friendly bollard with no uplight and is DLC Luna certified. Available in 2700K, 4000K and 5000K CCT, this bollard series has high performance optics designed to fully eliminate glare for pedestrians and drivers passing by.
Features & Benefits of SMTH6 LED Bollard
- Aesthetic, slim, modern fixture design.
- 3 heights to choose from: 12”, 24”, 36”.
- Full cut-off design eliminates uplight and light pollution. Optics are hidden
from line of sight limiting glare while creating a comfortable experience
for passersby. - Innovative optic design creates even and uniform light distribution
across the surface. High performance optics allow for more spacing
between bollards reducing the number fixtures needed in an install. - 2700K, 4000K, 5000K colour temperature options.
- Custom paint finishes available.
- Extruded aluminum shaft, cast aluminum head and base with polyester
powder coat paint finish - IP66 rated – Designed to fully protect from dust ingress and
powerful water jets. - IK10 Rated – As per IEC 62262 Standard
- Twist Lock mechanism with stainless set screws for easy installation.
- Set of three zinc plated 8’’ long 3/8-16’’ anchor bolts with nuts and washers
Specifications
| Model | SMT6H12-LED10 | SMT6H24-LED20 | SMT6H36-LED24 |
| Watts | 8 | 20 | 25 |
| Lumens | 840 | 2100 | 2625 |
| Efficacy | 105 | 105 | 105 |
| Voltage | 120-277*, 347 V | 120-277*, 347 V | 120-277*, 347 V |
| CCT | 2700K, 4000K*, 5000K | 2700K, 4000K*, 5000K | 2700K, 4000K*, 5000K |
| Dimming | 1-10V Dimming | 1-10V Dimming | 1-10V Dimming |
| THD | <20% | <20% | <20% |
| Power Factor | 0.95 | 0.98 | 0.95 |
| Beam Distribution | Type V (360 degrees) | Type V (360 degrees) | Type V (360 degrees) |
| LED Life | >50,000 hours | >50,000 hours | >50,000 hours |
| Housing Finish | Bronze*, Custom Colours | Bronze*, Custom Colours | Bronze*, Custom Colours |
| Housing Details | Extruded Aluminum shaft, cast aluminum head and base | Extruded Aluminum shaft, cast aluminum head and base | Extruded Aluminum shaft, cast aluminum head and base |
| Surge Protection | 6kV (inbuilt surge suppressor) | 6kV (inbuilt surge suppressor) | 6kV (inbuilt surge suppressor) |
| Height | 12″ | 24″ | 36″ |
| Shaft Diameter | 5.3″ | 5.3″ | 5.3″ |
| Operating Temp. | -40 to +40 Celsius (-40 to 104 Fahrenheit) | -40 to +40 Celsius (-40 to 104 Fahrenheit) | -40 to +40 Celsius (-40 to 104 Fahrenheit) |
| Certifications | ETL, Wet Locations, IP66, IK10, DLC, LUNA, DLC 5.1 | ETL, Wet Locations, IP66, IK10, DLC, LUNA, DLC 5.1 | ETL, Wet Locations, IP66, IK10, DLC, LUNA, DLC 5.1 |
